SO218-38B

208- to 240-volt 1-phase 60-Hz air-cooled high-capacity frozen beverage dispenser

Name: 208- to 240-volt 1-phase 60-Hz air-cooled high-capacity frozen beverage dispenser
Brand: Stoelting Foodservice

Where to Buy

Request A Quote Where to Buy

With two large freezing cylinders for high-volume dispensing and quick recovery, this 208-240 volt, 1-phase, 60-Hz, air-cooled, high-capacity frozen beverage dispenser offers twice the capacity of the SO218 and SO318 models. Convenient, efficient and easy to use, it produces thick, stackable slush for post-mixing, and it’s versatile enough to adapt to either a bag-in-box or remote, premix auto-fill system. The fast-dispense function allows you to fill pitchers quickly, while the controlled dispense function lets you efficiently dispense drinks by the glass. Plus, it keeps the mixture visible and constantly in motion to attract attention and make the beverage look its best.

208- to 240-volt, 1-phase, 60-Hz, air-cooled
Extra-high capacity with two 14,000 BTU/hr compressors, two 2-gallon freezing cylinders and two 4 ½-gallon mix hoppers for high-volume dispensing and quick recovery
Produces thick, stackable slush for post-mixing
Adapts to either a bag-in-box or remote, premix auto-fill system
Fast dispense to fill pitchers quickly. Controlled dispense for drinks by the glass
Mixture is continuously visible and moving to showcase product
External, removable air filter
Front-to-rear airflow is quiet and efficient

Product Specifications

Model Information

Name	Value
UPC	671080276915

Unit Dimensions

Name	Value
Overall Dimensions (IN)	17-1/2 x 26-3/8 x 64-1/2
(W) Width (IN)	17.5
(D) Depth (IN)	26.37
(H) Height (IN)	64.5
Overall Dimensions (CM)	44.5 x 67 x 163.8
(W) Width (CM)	44.5
(D) Depth (CM)	67
(H) Height (CM)	163.8

Electrical

Name	Value
Frequency (Hz)	60
Hardwired Connection	No
Hz	60
Phase	1
Plug	NEMA 6-20P
Plug Connection	Yes
Running Amps	13.9
Voltage	208-240

Weight

Name	Value
Weight (LB)	315
Weight (KG)	142.9

Construction

Name	Value
Refrigerant	R448A

Frozen Treat: General Specifications

Name	Value
Cooling	Air
Compressor (Btu/hr)	12000
Number of Drive Motors	1
Drive Motor (hp)	1/2
Number of Hoppers	1
Number of Freezing Cylinders	1
Number of Freezing Cylinder Compressors	1
Air Flow	Units require 3" (7.6 cm) air space at the front and back.

Frozen Treat: Capacity Specifications

Name	Value
Hopper Capacity (GAL)	7
Hopper Capacity (L)	26.5
Total Hopper Capacity (GAL)	7
Total Hopper Capacity (L)	26.5
Freezing Cylinder Capacity (GAL)	2
Freezing Cylinder Capacity (L)	7.57
