CW2-37B
Countertop Whipped Crème Dispenser 2.11-quart, 115-Volt, Air-Cooled
Easy to clean and effortless to operate, this countertop whipped cream dispenser makes a huge impact with a small footprint. No chemical additives or propellants. Simply pour liquid cream into the hopper, and press the dispense button to deliver consistent product texture every time.
- 2.11-quart, 115-volt, air-cooled
- No chemical additives or propellants
- 52 quarts output per hour or 13-gallons output per hour
- Easy to own, use and maintain
- Compact design requires 12-inches clearance at the back, sitting flush to the wall for optimal countertop usage
- Adjustable dispense rate for optimal product output
- Air-cooled, 115-volt, 8-amp
Product Specifications
Model Information
| Name | Value |
|---|---|
| UPC | 671080594194 |
Unit Dimensions
| Name | Value |
|---|---|
| Overall Dimensions (IN) | 10 x 17 x 16-1/2 |
| (W) Width (IN) | 10 |
| (D) Depth (IN) | 17 |
| (H) Height (IN) | 16.5 |
| Overall Dimensions (CM) | 25.4 x 43.2 x 41.9 |
| (W) Width (CM) | 25.4 |
| (D) Depth (CM) | 43.2 |
| (H) Height (CM) | 41.9 |
Electrical
| Name | Value |
|---|---|
| Frequency (Hz) | 60 |
| Hardwired Connection | No |
| Hz | 60 |
| Phase | 1 |
| Plug | NEMA 5-15P |
| Plug Connection | Yes |
| Running Amps | 8 |
| Voltage | 115 |
Weight
| Name | Value |
|---|---|
| Weight (LB) | 62 |
| Weight (KG) | 28.1 |
Construction
| Name | Value |
|---|---|
| Refrigerant | R-134a |
Frozen Treat: General Specifications
| Name | Value |
|---|---|
| Cooling | Air |
| Compressor (Btu/hr) | 290 |
| Number of Drive Motors | 1 |
| Drive Motor (hp) | 0.4 |
| Number of Hoppers | 1 |
| Air Flow | Units require 12" (30.5 cm) air space at the back |
Frozen Treat: Capacity Specifications
| Name | Value |
|---|---|
| Hopper Capacity (GAL) | 0.53 |
| Hopper Capacity (L) | 2.01 |
| Total Hopper Capacity (GAL) | 0.53 |
| Total Hopper Capacity (L) | 2.01 |
Product Downloads
Stoelting product CAD drawings
Click below to view the most up-to-date list of Stoelting products and CAD drawings.
CAD / REVIT
