SF111-38IP
380- to 415-volt 3-phase water-cooled pressurized twin-twist soft serve ice cream and frozen yogurt freezer with 16-gallon refrigerated mix storage cabinet
Single-flavor, countertop, gravity-fed, soft serve/yogurt freezer with attached spinner. Compact, space-saving unit that can handle peak demands. IntelliTec control for worry-free operation. ECM (Energy Conservation Mode) to prevent over-agitation. Optional floor stand to create a 'floor model' package freeing up counter space and providing additional storage.
- Hard-working, compact counter-top unit handles peak demands, while providing years of dependable service.
- Production Capacity: 11 gallons per hour.
- 208-230/60/1 Air
- Gravity Fed
- IntelliTec™ control communicates with the operator for worry-free operation.
- Proprietary auger design gently folds mix and prevents product breakdown, producing a smoother, creamier product.
- Long-wearing parts offer lower preventative maintenance costs.
- Clear door provides excellent product visibility and merchandising appeal.
- Optional floor stand to create a “floor model” package, freeing up counter space and providing additional storage.
- Attached spinner conveniently blends syrups or mix-ins.
Product Specifications
Model Information
| Name | Value |
|---|---|
| UPC | 671080878881 |
Unit Dimensions
| Name | Value |
|---|---|
| Overall Dimensions (IN) | 18-1/8 x 28-7/8 x 35-5/8 |
| (W) Width (IN) | 18.12 |
| (D) Depth (IN) | 28.87 |
| (H) Height (IN) | 35.62 |
| (WL) Width between legs | 9.25 |
| (DL) Depth between legs | 16.75 |
| Overall Dimensions (CM) | 46 x 73.3 x 90.5 |
| (W) Width (CM) | 46 |
| (D) Depth (CM) | 73.3 |
| (H) Height (CM) | 90.5 |
| (WL) Width between legs (CM) | 23.5 |
| (DL) Depth between legs (CM) | 42.5 |
Electrical
| Name | Value |
|---|---|
| Frequency (Hz) | 60 |
| Hardwired Connection | No |
| Hz | 60 |
| Phase | 1 |
| Plug | NEMA 6-15P |
| Plug Connection | Yes |
| Running Amps | 8 |
| Voltage | 208-240 |
Weight
| Name | Value |
|---|---|
| Weight (LB) | 280 |
| Weight (KG) | 127 |
Construction
| Name | Value |
|---|---|
| Refrigerant | R448A |
| Product Function | Soft Serve & Frozen Yogurt Countertop Machines |
Frozen Treat: General Specifications
| Name | Value |
|---|---|
| Cooling | Air |
| Compressor (Btu/hr) | 6300 |
| Number of Drive Motors | 1 |
| Drive Motor (hp) | 3/4 |
| Number of Hoppers | 1 |
| Number of Freezing Cylinders | 1 |
| Air Flow | Units require 3" (7.6 cm) air space on both sides |
Frozen Treat: Capacity Specifications
| Name | Value |
|---|---|
| Hopper Capacity (GAL) | 3 |
| Hopper Capacity (L) | 11.36 |
| Total Hopper Capacity (GAL) | 3 |
| Total Hopper Capacity (L) | 11.36 |
| Freezing Cylinder Capacity (GAL) | 0.85 |
| Freezing Cylinder Capacity (L) | 3.22 |
Product Accessories
Product Downloads
Stoelting product CAD drawings
Click below to view the most up-to-date list of Stoelting products and CAD drawings.
CAD / REVIT
