U3-02A
208- to 240-volt 3-phase 60-Hz water-cooled single-flavor soft serve and frozen yogurt freezer with refrigerated mix storage cabinet
Keep up with high demand while maintaining a delicious quality product with this durable, reliable single-flavor, pressure-fed soft serve and frozen yogurt freezer. Ideal for restaurants, drive-ins, recreational facilities, schools, cafeterias and ice cream parlors, this 208- to 240-volt, three-phase, 60-Hz, water-cooled unit features a high-dispense rate and high production capacity with a high-efficiency evaporator, 15,000 BTU/hr Scroll™ compressor and 2-hp drive motor. The refrigerated mix storage cabinet features a slide-out shelf to hold two 8-gallon-mix containers. Plus, the proprietary auger design ensures a smoother, creamier product, while you enjoy the convenience and capabilities of intuitive and configurable Intellitec2® controls.
- 208- to 240-volt, 3-phase, 60-Hz, water-cooled
- Maintains high production in high-temperature conditions
- Enjoy maximum reliability and quieter operation with high-efficiency evaporator and 15,000 BTU/hr Scroll™ compressor
- Intuitive Intellitec2 control communicates critical, full-text information through a multiline graphics LCD display
- Energy Conservation Mode (ECM) protects product from over agitation during slow or nondraw periods
- Refrigerated mix storage cabinet features a slide-out shelf to hold two 8-gallon-mix containers
- Mix pump injects a precise amount of air into the mix, maintaining consistent overrun and maximizing profitability with clean-in-place simplicity
- Proprietary auger design gently folds mix to prevent product breakdown for a smoother, creamier product
Product Specifications
Model Information
| Name | Value |
|---|---|
| UPC | 029419969258 |
Unit Dimensions
| Name | Value |
|---|---|
| Overall Dimensions (IN) | 9-3/4 x 10-1/2 x 8-1/2 |
| (W) Width (IN) | 9.75 |
| (D) Depth (IN) | 10.5 |
| (H) Height (IN) | 8.5 |
| Overall Dimensions (CM) | 24.8 x 26.7 x 21.6 |
| (W) Width (CM) | 24.8 |
| (D) Depth (CM) | 26.7 |
| (H) Height (CM) | 21.6 |
Electrical
| Name | Value |
|---|---|
| Frequency (Hz) | 60 |
| Hardwired Connection | No |
| Hz | 60 |
| Phase | 1 |
| Plug | NEMA 5-15P |
| Plug Connection | Yes |
| Running Amps | 1.6 |
| Voltage | 115 |
Weight
| Name | Value |
|---|---|
| Weight (LB) | 27 |
| Weight (KG) | 12.2 |
Case Lot Measurement
| Name | Value |
|---|---|
| Case Width | 11 |
| Case Height | 12 |
| Case Length | 13 |
Product Downloads
Stoelting product CAD drawings
Click below to view the most up-to-date list of Stoelting products and CAD drawings.
